Hydraulic Crawler Chassis Mounted Diamond Core Drilling Rig For Mine Drilling And SPT Test With Drill Tower
Portable Water Well Drilling Rig troduce
Drilling Rig is a crawler chassis mounted mining core drilling rig. It is specially designed for engineering geological explorations for railway, hydropower, highway, bridge and dam etc, and SPT test. The CDL-100 Drill Machine can be used in geological projects, core drilling and geophysical exploration drilling, borehole drilling for small grouting, hole blasting and small water well.
Portable Water Well Drilling Rig parameters
| Drilling Capability | Drilling Diameter | Drilling Depth |
| 75-300mm | 120m |
| Drilling Speed in Soft Stratum | 20-30 m/h |
| Drilling Motor | 18HP |
| Lifting Capacity | 2 ton |
| Drilling Rods | 1.5m/pcs |
| Power of Diesel Engine | 22HP |
| Sewage Pump | 8HP |
| Dimension (L*W*H) | 2200*1500*2000mm |
Drilling rig characteristics
1,drilling rig has a hydraulic automatic feed mechanism, improve drilling efficiency,
reduce manual labor workers.
2. Card holder mechanism instead of using the ball chuck, can implement non-stop down the lever,
easy to operate, safe and reliable.
3. With bottom hole pressure gauge indicates the pressure, easy to grasp hole situation.
4 The handle centralized, easy to operate.
5. Light weight, decomposition and strong, easy to move, adapted to the plains or mountain areas.
Pre-Sale Service
Make clearly your requirement for the drilling rig, such as drilling depth and diameter, and the formation underground. As we know, drilling is a risky work, we might meet different problems during drilling because of different underground layer. No one drilling rig can deal with diverse formation. all different type drilling rig has its limit. So we will give you best suggestion accordingly. Drilling rig is machinery that never purchased by specifiction. Normally, the capacity in specification is just for reference, such as if it marks 100m depth at most, only in ideal case could it reach to 100m. This will be a big problem if you have no idea about drilling. And we always guide our customer in a right way, not only sell machine, just make sure our customer can use our drilling rig properly.
